Dell Latitude 7480 BIOS CAZ20 LA-E131P
boardview Dell Latitude 7480 - LA-E131P Boardview (.CAD).cad
Schematics
LA-E131P BOTTOM.pdf
LA-E131P TOP.pdf
boardview Dell Latitude 7480 - LA-E131P Boardview (.CAD).cad
Schematics
LA-E131P BOTTOM.pdf
LA-E131P TOP.pdf
About this board
This thread is for the Dell Latitude 7480 CAZ20 with main board LA-E131P.
Dell had this board built by Compal; Compal board numbers start with LA- and end in P. Check the number printed on the PCB before you download.
What this thread covers
- BIOS (full SPI chip dump, .bin)
- Schematic (PDF)
Common cases: dead board after an interrupted BIOS update, ME region errors, missing serial number or UUID after a board swap, or a password lock.
Before flashing, always read and save the original chip. It holds the serial number, UUID, MAC address and ME data for that exact machine.
If you have a working file for this board, please share it below. More files: search LA-E131P in File Finder.
